Options:

- Automation

- Reverse roll not available

- Side Channels not available

Colours:

White, Black, Espresso, Alabaster, Anodized Aluminum

Light Gap:

Clutch: 5/8"

Idle End:7/16"

DC Motor: 5/8"

Idle End:7/16"

AC Motor:1"

Idle End:7/16"

Must Specify:

- Cassette size and colour (if no colour is provided, Elite will colour-coordinate cassette to shade fabric).

- Ceiling or wall mount brackets

Cassette Fabric Limitations

1) INTERMEDIATE BRACKETS

Joins multiple shades together with one motor or chain control to operate as a single unit (L or R control). This can be an economical way of covering a wide set of windows, especially when automating the shades; only one motor is used. However, shades cannot be operated individually.

Max. Combined Width: 120". Individual shade widths cannot exceed limits on previous page.

Price As:

individual shades plus cassette (total width) plus net per intermediate bracket.

Light Gap:

Clutch: 5/8"

Middle 3/8"

Idle End:7/16"

DC Motor: 5/8"

Middle 3/8"

Idle End:7/16"

AC Motor:1"

Middle 3/8"

Idle End:7/16"

Max. Combined Width: 120".

Individual shade widths cannot exceed limits on previous page.

Price As:

individual shades plus cassette (total width)plus net for centre support bracket.

Light Gap:

Clutch: 5/8"

Middle 3/8"

DC Motor: 5/8"

Middle 3/8"

AC Motor:1"

Middle 3/8"

1) Hem Pocket

Most Solar Shade fabrics will be made with a hem pocket bottom rail unless otherwise specified. See fabric specs on page DSS5 for exceptions.

• Compatible with most Solar shade fabrics. See fabric index for availability.
• Not compatible with side channels.
• Not available with hold-down brackets

2) Fabric Insert Bottom Rail

All Designer Shade fabrics will be made with a colour coordinated fabric insert bottom rail unless otherwise specified:

Not available with Room Darkening Side Channels

• Available in Regular and XL Sizes (please specify)
• Compatible with all fabrics
• Compatible with hold-down brackets
• Compatible with side channels
• XL size is recommended for large motorized shades for added weight and stability

Colours:

White, Black, Espresso, Alabaster, Anodized Aluminum

3) Exposed Bottom Rail

Suitable for both Solar and Designer Shades by request only. Please specify colour.

• Available in Regular and XL Sizes (please specify)
• Compatible with all fabrics
• Compatible with hold-down brackets
• Compatible with side channels
• XL size is recommended for large motorized shades for added weight and stability

Colours:

White, Black, Espresso, Alabaster, Anodized Aluminum

General Information

Dye Lot

Colours of dye lots may vary within commercial tolerances. Colours of fabrics may vary from samples. We cannot guarantee exact dye lots as sampled.THIS APPLIES TO ALL PRODUCT LINES. If two or more shades are butted together or installed in the same room, it is the Dealer's responsibility to inform us when placing the order so that the shades will be cut from the same dye lot.Matching dye lots may cause delay in delivery. We cannot guarantee dye lots on subsequent or different orders.

Chain and Motor Controls

Always specify if roller shade is to have left or right hand chain or motor controls. If not specified, factory will supply right control. If extra long or short chains are required,please specify at time of order.

Measuring Information

Measuring

Accurate measurements are essential. Be sure to use a quality steel tape since cloth tapes or wood rulers are not dependable for precise measurements. Measure all windows, even though they may appear to be identical.The factory will make the blind exactly the size ordered within tolerances of +1/8". The following guidelines should be used in measuring all roller shades:

Tip Measure

Tip measure is the measure from the outside edge of one pin, to the outside edge of the other pin.

Cloth Measure

If an exact cloth measure is required, specify "CLOTH MEASURE" when ordering. Note that the tube and brackets will extend beyond specified width approximately 1�".

Measuring Height

Measure height of window opening from top of frame to lower sill. Wrap is included in the suggested retail price.

Inside Mount

Measure the exact distance between the points where the brackets are to be installed and deduct" for roller clearance or order inside mount tight and Elite will deduct 1/4". Specify tip measure.

Outside Mount

Measure the exact distance between the points where the brackets are to be installed. Specify tip measure.

Ceiling Mount

See Inside Mount (above). Where overlap is required add 3" to each side.

ALL BLINDS ORDERED BEYOND ELITE'S SPECIFICATIONS/RECOMMENDATIONS WILL NOT BE COVERED UNDER THIS WARRANTY. ANY ALTERATIONS BY THE CUSTOMER TO THE HARDWARE, MOTORS, FABRIC, OR ANY OTHER COMPONENT OF THIS PRODUCT AFTER SHIPPING WILL VOID THIS WARRANTY.
