Options:

- Automation

- Reverse roll not available

- Side Channels not available

Colours:

White, Black, Espresso, Alabaster, Anodized Aluminum

Light Gap:

Clutch: 5/8"

Idle End:7/16"

DC Motor: 5/8"

Idle End:7/16"

AC Motor:1"

Idle End:7/16"

Must Specify:

- Cassette size and colour (if no colour is provided, Elite will colour-coordinate cassette to shade fabric).

- Ceiling or wall mount brackets

Cassette Fabric Limitations

Linked shades are designed to cover window spans that are too wide for a single shade. This options is advantageous when railroading a fabric is not desired or not possible. Gaps between shades will be narrowerwhen compared to separately installed shades, and gaps can be aligned with window mullions or frames for a clean and uniform look. Linked shades also allow the use of a single seamless cassette to house each shade.

2) CENTRE SUPPORT BRACKETS

Joins two shades together with separate clutch or motor controls allowing the customer to operate each shade independently. Two clutch controls or motors are required (L & R control).

CHAIN CONTROL OPTIONS

Plastic Chain Colours: Black, White, Grey, Espresso, Alabaster

Steel Chain Colours: Steel

Unless Otherwise Specified:

a. All Designer Shade fabrics will be supplied with colour coordinated plastic chain

b. All Solar Shade fabrics will be supplied with steel chain.

See fabric specifications pg DSS4-5 for details.

Standard Continuous Loop Lengths: 24", 36", 48", 60", 72", 96".

Exact lengths of steel chain only are available upon request.

TUBE OPTIONS

Elite automatically selects the clutch and tube size for your shade unless otherwise specified.

BOTTOM RAIL OPTIONS

Elite offers three bottom rail options to complement or accent your shade�s decor. Bottom rails are fastened to the bottom edge of the fabric to add weight, stability, and visual appeal to the shade. Please specify your bottom rail choice on your order. If no bottom rail is specified, Elite will supply a default bottom rail based on your fabric selection (noted below).

Fabric Name	Fabric Composition	Railroadable Seamable Printable	Width	OF	FR	Bot. Rail	Chain	Roman Panel	Thickness Group
E Screen Original 3%	36% Fiberglass, 64% PVC	R, S	98"	3%		HEM	ST	R / P	2
E Screen Original 5%	36% Fiberglass, 64% PVC	R, S	98"	5%		HEM	ST	R / P	2
E Screen + KoolBlack 3%	36% Fiberglass, 64% PVC	R, S	98"	3%		HEM	ST	R / P	2
E Screen + KoolBlack 5%	36% Fiberglass, 64% PVC	R, S	98"	5%		HEM	ST	R / P	2
EM Screen 3%	36% Fiberglass, 64% PVC	R, S, P*	98"	3%		HEM	ST	R / P	2
EM Screen 5%	36% Fiberglass, 64% PVC	R, S, P*	98"	5%		HEM	ST	R / P	2
EM Screen Deco	36% Fiberglass, 64% PVC		98"	5%		HEM	ST	R / P	2
EM Screen ECO	100% Polyester		118"	3%		INS	ST	R / P	1
EM Screen Twilight	100% Polyester/Acrylic coating	R, S	110"	BO		INS	ST	R / P	3
EnviroScreen G2	100% Trevira CS Polyester		94"	2%		INS	ST	R / P	2
EnviroScreen Naturals	100% Trevira CS Polyester		94"	3%		INS	ST	R / P	2
Juneau	100% Polyester	R, S	110"	BO		INS	ST	R / P	3
Metallic Elite	100% Polyester	R	102"	BO		INS	ST	R / P	1
MicroWeave	30% Polyester, 70% PVC	R, S, P*	98"	3%		HEM	ST	R / P	1
SheerWeave� 2701	36% Fiberglass, 64% PVC	R, S, P*	98"	1%		HEM	ST	R / P	3
SheerWeave� 4000	25% Polyester, 75% PVC	R, S, P*	98"	5%		HEM	ST	R / P	3
SheerWeave� 4100	25% Polyester, 75% PVC	R, S, P*	98"	10%		HEM	ST	R / P	3
SheerWeave� 4400	25% Polyester, 75% PVC	R, S, P*	98"	3%		HEM	ST	R / P	3
SheerWeave� 4800	24% Polyester, 76% PVC	R, S, P*	96"	1%		HEM	ST	R / P	3
SheerWeave� 5000	Polyester, Vinyl, Acrylic, Olefin	R, S	98"	3-7%		INS	ST	R / P	3
SheerWeave� 7100	PVC-Coated Fiberglass	P	96"	BO		HEM	ST	R / P	3
SilverScreen� 2%	36% Fiberglass, 64% PVC	R, S	94"	2%		INS	ST	R / P	2
SilverScreen� 4%	36% Fiberglass, 64% PVC	R, S	94"	4%		INS	ST	R / P	2
Sol-Shade 1%	30% Polyester, 70% PVC	R, S, P*	118"	1%		HEM	ST	R / P	3
Sol-Shade 3%	30% Polyester, 70% PVC	R, S, P*	118"	3%		HEM	ST	R / P	2
Sol-Shade 10%	30% Polyester, 70% PVC	R, S, P*	118"	10%		HEM	ST	R / P	2
Solar Weave 3%	25% Polyester, 75% PVC	R, S, P*	118"	3%		HEM	ST	R / P	3
Solar Weave 5%	25% Polyester, 75% PVC	R, S, P*	118"	5%		HEM	ST	R / P	3
Solar Weave 10%	25% Polyester, 75% PVC	R, S, P*	118"	10%		INS	ST	R / P	3
Solaris	28% Polyester, 68% PVC, 4% Aluminum	R, S	98"	4%		HEM	ST	R / P	2
Zenith 3%	25% Polyester, 75% PVC	R, S, P*	98"	3%		HEM	ST	R / P	3
Zenith 5%	25% Polyester, 75% PVC	R, S, P*	98"	5%		HEM	ST	R / P	3

SPRING ASSISTS

Long and Narrow Spring Assist:

Recommended for fabric thickness groups 2 & 3 that are narrower than 72" wide and longer than 102" high.

Regular Spring Assist:

Recommended for fabric thickness groups 2 & 3 that are larger than 96" W x 96" H.

Heavy Duty Spring Assist:

Recommended for fabric thickness groups 2 & 3 that are larger than 120" W x 96" H when using intermediate brackets.

Suggested Retail Price for all Springs: $120

INDEXABLE COUPLERS FOR LARGE AUTOMATED SHADES

Indexable couplers are used with motorized Z-200 or Z-400 hardware systems with linked shade options. The couplers are compatible with 2" and 2" tubes. One coupler set is needed per intermediate bracket and includes one male and one female coupler plus a plastic wrench. Both couplers feature retractable idler pins for easy installation. The wrench is used to rotate the spindles and retract pin. The Male coupler can be pulled apart to reveal indexable grooves, which can be rotated to adjust shade height +/- 1/16". This feature ensures each bottom rail is properly aligned and all shades are the same height.

MEASURING INSTRUCTIONS

We recommend the use of a quality steel measuring tape for all measurements.

Inside Mount

Measure the exact width and length of the window openinig as shown. The factory will deduct 3/8 off the width of the shade for clearance. Please mark and specify inside or tight measurement on your order form.

Outside Mount

Measure the exact width and length of the window opening you wish to cover. The shade should overlap the window opening by at least 2” on both width and length. Please mark and specify outside mount or r finished measurement on your order and also specifiy whether you require valance returns.
