See colour coordination chart pg SHS2 for cassette colours.

S-300 Cassette will have complementary fabric insert.

S-350 Cassette will have complementary fabric insert where available, see colour coordination chart pg SHS2.

Available with Elite Smart Shades� automation.

Available with centre support (2-on-1) controls.

White, Black, Espresso, Alabaster, Anodized Aluminum

Clutch: ⅝" Idle End: 7/16" DC Motor: ⅝" Idle End: 7/16" AC Motor: 1" Idle End: 7/16"

Please specify ceiling or wall mount installation brackets.

Before ordering, please reference both the fabric specification chart for fabric width & thickness group and check the size limitation chart below for maximum shade height.

Size Limitation Chart

Fabric Specifications

Colour Coordination Chart

Fabric	Fabric Colour	Cassette Colour	S-350 Insert
Horizon	Cloud	White
Horizon	Cream	White
Horizon	Fawn	Alabaster
Horizon	Glacier	White
Horizon	Marshmallow	Alabaster
Horizon	Swan	White
Sheena	Cameo	Alabaster
Sheena	Platinum	Anodized
Sheena	Quartz	White
Sheena	Silver	Anodized
Sheena	Topaz	Alabaster
Vision	Cream	Alabaster
Vision	Desert Tan	Alabaster
Vision	Grey	Anodized
Vision	Ivory	Alabaster
Vision	Mushroom	Alabaster
Vision	Winter White	White

On your order please specify:

• - fabric name
• - vane size
• - openess
• - colour name (and number if applicable)

IMPORTANT NOTE:

UNLESS OTHERWISE SPECIFIED, the cassette and hardware will be colour coordinated with shade fabric as per the colour chart above.

Please specify wall or ceiling mount installation brackets. Inside Mount (if tight measurements are given): Cassette will measure ordered width less: �". INSIDE Fabric will measure ordered width less 1⅜". Outside Mount: Cassette will measure ordered width.
INSIDE
Fabric will measure ordered width less 1â…›". JAMB
OUTSIDE
INSIDENOTE ON FABRIC LENGTH
The finished dimensions for both width and height may vary +⅛" from OUTSIDE your ordered measurements. For all mounting types, the shade will SILL measure the length ordered when the vanes are in the open or "view-through" position. However, the height will be ⅜" longer when the vanes are in the closed position. As a result on an inside mount, a slight puckering can occur on the lower-most sheer section because of the contact with the window sill. To compensate, slightly raise the open closed shading until the rail begins to lift off the window sill. If preferred, the shade can be ordered ⅜" less than the window opening's measured height. In this case, the bottom rail will be positioned ⅜" above the sill when the vanes are in the open position (see diagram at right). Rotating the vanes closed will cause the bottom ⅜" rail to touch the window sill, closing the light gap between the sill and the shade.
Side-By-Side Alignment
When Sheer Horizontal Shades are installed side by side, cell alignment can be guaranteed with in �" only if: a) The shades are the same colour and ordered at the same time. b) The sum of the widths of all shades needing alignment is less than 112". c) Side by side alignment must be specified when the order is placed. MEASURING GUIDELINES
Precise width and height measurements are critical. Please use a metal measuring tape for best accuracy when taking
measurements. The headrail must be installed perfectly level and installed evenly to ensure smooth operation. For
Inside Mount, it is recommended to check whether the mounting surface is level and consistent. If your soffit needs to be leveled, this should be done before measuring.
Inside Mount
Measure across the width of your window opening in three different places: top, middle and bottom. Measurements should be taken within the window jamb. Provide the smallest of the three measurements to Elite - be exact! Elite will make the necessary deductions to fit the window opening. Measure the length of the window opening from the underside of the soffit to the surface of the window sill in two places; use the smallest of these two measurements.
Outside Mount
Measure the exact width and length of the area to be covered. On the width, allow at least 1�" of an overlap on each side. An overlap of 3" on each side is recommended. Be sure to take into consideration any obstructions such as, moldings, locks, and window cranks. Repairs: A Minimum charge of .00 net cost plus shipping applies to all repairs, alterations and parts. 1" minimum required to cut down on width.
